Sensor: 1D Laser
Aiming Element: Visible laser diode 650 nm
Illumination: Hyper Red 660nm
Pitch Angle: ±40°
Roll Angle: ± 35° from vertical
Optical Resolution: 4 mil (0.1mm)
Depth of Field:
Symbology | Density | Near | Far
5 mil Code 128 | 3.55 cm | 17.78 cm
5 mil Code 39 | 3.05 cm | 26.67 cm
7.5 mil Code 39 | 3.04 cm | 41.91 cm
10 mil Code 128 | 3.05 cm | 40.46cm
13 mil UPC | 4.57 cm | 63.50 cm
15 mil Code 128 | 5.08 cm | 66.04 cm
20 mil Code 39 | 3.56 cm | 116.84 cm
55 mil Code 39 | 8.64 cm | 177.80 cm
100 mil Code 39 | 60.96 cm | 457.20 cm
Communication: Serial port and HID port
Supported Host Interface: USB
Dimensions: 87.8 L x 71.6 W x 177.7 H (mm)
Weight: 213g without cradle
Trigger Switch Life: 10 million times
Barcodes: 1D
Indicators: LED & Beeper & Vibrator
ESD Protection: Functions after 8K Contact and 15K Air
Mechanical Shock: 2.1M drop to concrete (scanner only)
Operating Temperature: -10°C to 50°C (14°F to 122°F)
Storage Temperature: -40°C to +70°C (-40°F to +158°F)
Standard: IP42
Accessories (Optional):
■ USB Cable (PN# 1550-905904G)
■ 1-slot Charging Cradle (PN#5000-900074G)
■ Battery Pack (PN# 1400-900055G)
Certifications: CE, FCC, BSMI, VCCI, NCC, TELEC, BQB
Memory: 7MB for batch mode/ 20KB for auto mode
Key: Trigger Key
Wireless Coverage: 100m (line of sight)
Battery Type: Rechargeable and replaceable battery pack.
Battery Capacity: 2850mAh
Battery Charging Time: <6.5 hours
Operating Time: >30 hours Up to 50,000 scans in 1 scan/5 seconds
Scan Rate: 104 (± 12) scans/second (bi-directional)
Bluetooth: Bluetooth LE V4.2 Bluetooth 2.1+EDR, Dual mode Class 2
