Frequency range : 9 kHz-3.6 GHz
Frequency resolution : 1Hz
Sweep range : 0Hz,100Hz - 3.6GHz
Sweep accuracy : Swept ±[0.25%*Span+Span/(Points-1) ]; FFT ±[0.10%*Span+Span/(Points-1) ]
Sweep time : 1 ms to 4000 s(span≠ 0); 1 μs to 4000 s(span= 0)
Sweep mode : Swept,FFT
Marker mode : Normal, Delta Δ, Fixed
Marker function : Marker Noise, Band Power, Band Density, NdB, Counter
RBW (-3 dB) : 1 Hz-3 MHz,1-3-10 steps
Video bandwidth (VBW): 1 Hz-3 MHz,1-3-10 steps
Selectivity (–60 dB/–3 dB) : <4.8:1 (nominal)(-60dB:-3dB)
Bandwidth accuracy (–3dB) : < 5% (nominal)
Reference level : -100 dBm - +30 dBm,Steps 1 dB
Preamp : 20 dB,Nominal
Input attenuator range: 0-51 dB,1 dB Steps
Maximum input DC voltage : 50 V DC max
Maximum continuous wave RF power: ≤+33 dBm 3 minute,Input attenuation >20 dB
Display log scale: 1 dB to 200 dB
Display linear scale: 0 -Reference level
Scale units : dBm,dBmV,dBuV,V,W
Sweep (trace) point range : 40001
Number of traces : 6
Detection mode : Sample,Peak,Negative,Normal,Average
Trace Type : Clear/Write,Average,Max Hold,Min Hold
Frequency response:
Preamp Off : 9 kHz to 3.6 GHz:±0.6 dB;±0.3 dB,Typical; 3.6 GHz to 8.4 GHz:±0.8 dB;±0.6 dB,Typical
Preamp On : 100 kHz to 3.6 GHz:±1.0 dB ; ±0.8 dB ,Typical; 3.6 GHz to 8.4 GHz:±1.2 dB ; ±1.0 dB ,Typical
Tracking generator:
Frequency range: 100kHz-3.6 GHz
Output level range: -40 dBm-0 dBm
Resolution : 0.5 dB
Flatness output : ±3 dB
Interface : RF input,Trace source output,10MHz reference input, 10MHz reference output,Ext Trigger,HDMI,USB host, USB device,LAN,Headphone Jack
General Characterisitics:
Power : 100-240V AC, 50Hz/60Hz; 100 to 120 VAC (Fluctuations±10%),400 Hz
Display : 10.1 'TFT LCD (1280x800) touch
Product size(W×H×D) : 378 mm×218 mm×120 mm
Product net weight : 4.55kg
