Frequency range : 9kHz-3.6 GHz
Frequency resolution : 1Hz
Sweep width range : 0Hz,100Hz- 3.6GHz
Sweep accuracy: Swept: ±[0.25%×span+span/(sweep point -1)]; FFT: ±[0.10%×span+span/(sweep point -1)]
Sweep time : Span = 0 Hz, 1 μs to 4000 s; Span ≠ 0 Hz, 1 ms to 4000 s
Marker mode : Normal, Delta △ , Fixed
Marker function : Marker Noise, Band Power, Band Density, N dB, Counter
RBW (-3 dB) : 1 Hz - 10MHz (1-3-10 step)
Video bandwidth (VBW) : 1 Hz - 10MHz (1-3-10 step)
Selectivity (–60 dB/–3 dB) : <4.8:1(Nominal) -60dB:-3dB
Reference level : -100 dBm to +30 dBm,1 dB Steps
Preamplifier : +20 dBm nominal
Input attenuator range : 0 to 51 dB,1 dB Steps
Trace detectors : Sample,Peak,Negative,Normal,Average
Trace type: Clear/Write,Average,Max Hold,Min Hold
Scale units : dBm,dBmV,dBμV,V,W
Sweep (trace) point range : 40001
Tracking source : 100 kHz - 3.6 GHz
Vector network analysis : S11,S21,DTF
Advanced Measurement : Power Suite Measurement, Nonlinear Measurement, Spectrum Monitoring
Modulation Analysis : AM Measurement, FM Measurement ,PM Measurement
Vector signal analysis:
ASK:2ASK,4ASK,8ASK,16ASK
FSK: 2FSK,4FSK,8FSK,16FSK
MSK:type1,type2
PSK: BPSK,QPSK,OQPSK,8PSK,BPSK,QPSK,8BPSK;DQPSK,D8PSK,π/4 -DQPSK, π/8 -D8PSK,OQPSK
QAM: 16,32,64,128,256
Real-time analysis bandwidth : Up to 10 MHz; Option up to 40 MHz
Interface: RF input, TG Output,10MHz reference IN,10MHz reference OUT,External trigger input,HDMI,USB-Host,; USB-Device,LAN,3.5mm
General Characterisitics:
Power : 100-240V AC(±10%), 50Hz/60Hz; 100 to 120 VAC (Fluctuations±10%) 400 Hz
Display : 10.1" TFT LCD (1280x800) touch
Product size(W×H×D) 3: 78mm×218mm×120mm
Product net weight : 4.96 kg
