UNI-T UTR2830E LCR ແມັດ (20Hz~200kHz; 1V)

Display: 4.3''(480x272) TFT LCD

Frequency

+ Range: 20Hz~200kHz(Continually adjustable)

+ Accuracy: ±0.02%

AC level

+ Range: 10mVrms~2Vrms

+ Accuracy: 10% set value +2mV

DC level: Range: 1V

AC source internal resistance:

+ ISO ON: 100Ω

+ ISO OFF: 30Ω / 50Ω / 100Ω

DC bias voltage: Range: no

DCR internal resistance: 100Ω

Test parameters: L, C, R, |Z|, D, Q, |Y|, G, X, θd, θr, RDC, Vm, Im, △%

Accuracy: LCRZ 0.05%、DCR 0.1%

Test speed: Fast: 12.5ms; Medium: 83ms; Slow: 167ms

V/I monitor: yes

Calibration: Open, Short, Load

List : 201 Dots

Trigger: Internal, manual, external, bus

Average: 1~255

Comparator: 10 bins, BIN1–BIN9, NG, AUX; Bin count function

Storage: Internal: 100 sets of setting files, 201 test results

USB: Setting files, BMP images, CSV data files

Interface: RS232, HANDLER, USB HOST, USB DEVICE, LAN

Weight: 4.65kg

Size: 88mm×215mm×350mm
