Insulation resistance (Ω)
Output voltage:250V/500V/1000V
250V0.05MΩ～250MΩ
500V0.05MΩ～500MΩ
1000V0.05MΩ～1000MΩ
Short-circuit current: <2mA
Low-resistance continuity test
Range:0.00Ω～199Ω
Test current:0.00～2Ω: >200mA
Range:0.01Ω～2000Ω
Line impedance (Ω)
Operating voltage (Frequency):195V～440V (45Hz～65Hz)
Test current:20A
PFC test:0kA～26kA
Range:0.01Ω～2000Ω
Loop impedance (Ω)
Operating voltage (Frequency):195V～253V (45Hz～65Hz)
Test current:20A
PFC test:0kA～26kA
Range:1.00Ω～2000Ω
Non-trip loop impedance (Ω)
Range:1.00Ω～2000Ω
Operating voltage (Frequency):195V～253V (45Hz～65Hz)
Test current:15mA
PFC test:0kA～26kA
RCD test
Operating voltage (Frequency):195V～253V (45Hz～65Hz)
Test current:10mA/30mA/100mA/300mA/500mA
Phase sequence test
Operating voltage (Frequency):100V～440V (45Hz～65Hz)
DisplayPhase sequence: L1→ L2→ L3, forward rotation; L1→ L3→ L2 reverse rotation
Ramp RCD test
Test current:10mA/30mA/100mA/300mA/500mA
AC voltage (V)
Range:0V～440V
Frequency response:45Hz～60Hz
Resolution:1V
Features
Display count: 9999
Auto power off: √
Low battery indication: √
Data storage: √
LCD backlight: √
Auto half-wave test: √
RCD count down test:30s
RCD half-wave test: √
Phase conversion (RCD):0° and 180°
General Characteristics
Power:1.5V battery (5#) × 6
LCD size:125mm × 37mm
Product color:Red and grey
Product net weight:1000g
Product size:210mm × 175mm × 90 mm
Standard accessories:Battery, test leads (red×1, green×1, black×1), special power test lead, remote-control test lead
