Specification
Voltage(DCV):
600.0mV: ±(0.3%+5)
6.000V/60.00V/600.0V: ±(0.2%+5)
2500V: ±(1.0%+5)
Voltage(ACV) (45～1kHz): 600.00mV/6.000V/60.00V/600.0V/1500V: ≥45Hz, <500Hz: ±(0.8%+3); ≥500Hz, <1KHz: ±(1.8%+3);
VFD (ACV) ( 45～200Hz): 600.0V/1500V: ±(2.0%+5)
Auto Loz: (45～400Hz): 600.0V: ±(1.5%+5); 1500V: ±(1.8%+5)
ACV+DCV: 600.00mV/6.000V/60.00V/600.0V/1500V: ≥45Hz, <500Hz: ±(1.5%+5); ≥500Hz, <1KHz: ±(2.5%+5);
Resistance:
600.0Ω: ±(0.8%+5)
6.000kΩ/60.00kΩ/600.0kΩ/
6.000MΩ: ±(0.5%+5)
60.00MΩ: ±(2.5%+5)
Capacitance:
60.00nF: ±3.0%
600.0nF/6.000μF/60.00μF/
600.0μF: ±(3.0%+5)
6.000mF/60.00mF: ±(10.0%+5)
Continuity: 600.0Ω: ±(1.0%+5)
Diode: 3.2V: ±(1.0%+5)
Fequency: 99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz: ±(0.02%+5)
Duty cycle: 10Hz~10KHz (10%~90%): ±(2.0%+30)
Temperature: -40℃~1000℃: ±(1.0%+30); -40℉~1832℉: ±(1.0%+60)
External clamp (DCA): UT-CS07(optional): 100A(10mV/A) & 1000A(1mV/A): ±(0.8%+5)
External clamp (ACA): UT-CS07(optional): 45～400Hz: 100A(10mV/A) & 1000A(1mV/A): ±(1.0%+5)
AC Power 100A(10mV/A): Active power: 60.00kW/150.0kW: ±(3.0%+5)
Apparent power: 60.00kVA/150.0kVA: ±(2.0%+5)
Reactive power: 60.00kVAr/150.0kVAr: ±(5.0%+5)
Factor: -1~1: *
AC Power 1000A(1mV/A): Active power: 600.0kW/1500kW: ±(3.0%+5)
Apparent power: 600.0kVA/1500kVA: ±(2.0%+5)
Reactive power: 600.0kVAr/1500kVAr: ±(5.0%+5)
Factor: -1~1: *
DC Power 100A (10mV/A): 60.00kVA/250.0kVA: ±(3.0%+5)
DC Power 1000A (10mV/A): 60.00kVA/2500kVA: ±(3.0%+5)
Display count: 6000
Analog bar: 33 segment
True RMS: √
NCV: √
Auto range: √
REL.: √
PEAK: √
MAX/MIN: √
Data hold: √
High voltage alarm: √
High voltage OL alarm: √
Low battery indication: √
Auto power off: √
Multifunctional protection: √
Bluetooth app: √
Backlight: Auto backlight
Drop protection: 5m
IP rating: IP67
Working temperature: -40~55℃
Overvoltage category: CATⅣ1000V & CATⅢ1500V
General Characteristics
Product dimension: 220*104*67mm
Power supply: AA 1.5V *3
