Bandwidth : 2GHz
Channels: 4
Sample Rate : 10GSa/s(single channel), 5GSa/s (dual channel), 2.5GSa/s (full channel)
Memory depth : 1Gpts(single channel), 500Mpts(dual channel), 250Mpts(full channel)
Max. Waveform capture rate : ≥800,000 wfms/s(UltraAcq®);≥2,000,000 wfms/s (sequence mode)
Time base scale : 100ps/div-1000s/div
Input impedance : 1MΩ ± 1% (15±3 pF), 50Ω ± 2%
Vertical scale : 1mV/div-10 V/div (1 MΩ);1mV/div-1V/div (50Ω)
DC gain accuracy : 50Ω:±1.5%(≤5mV/div: ±2.0%)±1% of FS(≤5mV/div:±1.5% of FS); 1MΩ:±1.2%(≤5mV/div: ±1.5%)±1% of FS(≤5mV/Div: ±1.2% of FS)
Serial protocol analysis : Standard configuration: RS-232/422/485/UART, SPI, I2C, CAN, LIN; Optional: CAN-FD, SENT, FlexRay, AudioBus (I2S\LJ\RJ\TDM), MIL STD 1553, ARINC429
Waveform math: Simultaneous support for 8 math waveforms; Enhanced FFT, basic operations, filter, advanced function editor, MATLAB embedded programming operations and render, enhanced resolution;; Histograms, Area histograms, Trend chart, Trace
Auto measurements: >48 , support for parameter snapshots; support for statistical analysis, histograms, trend charts and tracking chart analysis
Number of measurements : Display 10 measurements at the same time
Measurement statistics : Current value, Average value, Maximum value, Minimum value, Standard deviation, Measure the count, Histogram, Trend chart, Trace
Arbitrary waveform generator (optional) : 1CH, 60MHz , 625MSa/s
Frequency counter : 8-bit hardware frequency counter
Digital voltmeter : 4-digit,DC/AC RMS/DC+AC RMS
Advanced analysis function : Power Analysis (Optional), Jitter and Eye Diagram Analysis (Optional), Limit Mask Testing, Sequence Mode
Standard interfaces USB Host ×4, USB Device ×1, LAN (10/100/1000Mb/s)×2, HDMI, Aux Out (Trig Out, Pass/Fail, AWG:
trigger output), 10MHz REF In\Out,Audio interface:
General Characterisitics:
Power : 100V-240V ACrms (±10%), 50Hz/60Hz
Product net weight : 3.5kg
Product size (W×H×D) : 214mm×43mm×500mm
Standard quantity per carton 1: pcs
Standard Accessories
Power cord conforming to the standard of the destination country
USB2.0 data cable
UT-P07:Passive probe x 4 (1 x, 10 x switchable, 500MHz)
UT-L45: BNC-BNC straight-through cable ×2
