Bandwidth : 500MHz
Channels : 4
Sample rate (analog) : 2.5 GSa/s (interweave mode),1.25 GSa/s (non-interweave mode)
Sample rate (digital) : 1.25GSa/s
Memory depth : 500Mpts
Max. Waveform capture rate: ≥500,000 wfms/s; ≥1,500,000 wfms/s (sequence mode)
Vertical resolution: 12-bit (ERES is enabled with a maximum of 16-bit)
Time base scale : 200 MHz (2 ns/div to 1 ks/div)
Input impedance : (1 MΩ±2%) || (18 pF±3 pF)50 Ω± 1.5%
Input impedance (digital) : (101 kΩ±1%)||(9 pF ± 1 pF)
Vertical scale : 500 μV/div - 10 V/div(1 MΩ) 500 μV/div -1 V/div(50 Ω)
DC gain accuracy : <5 mV: ±2% full scale,≥5 mV: ±1.5% full scale
Waveform record : 125,000 frames
Serial protocol analysis : Standard:RS232/UART, I2C, SPI; Optional:CAN, CAN-FD, LIN, FlexRay, AUDIO, MIL-STD-1553B, Manchester, SENT, ARINC429
Auto measurements : 54 kinds of parameter, simultaneously display 27 kinds of parameter measurement
Measurement statistics : Mean, Maximum, Minimum, Std Dev, Count, Tendency chart, Histogram
Arbitrary waveform generator (optional) : 2 CH, 50 MHz , 250 MSa/s
Frequency counter : 7-digit hardware frequency counter
Digital voltmeter: 4digits,DC/AC RMS/DC+AC RMS
Advanced analysis function : Power Analysis (Optional), BODE Plot (Optional), Limit Mask Testing
Standard interfaces : USB Host, USB Device, LAN, EXT Trig, AUX Out (Trig Out, Pass/Fail, DVM), Gen Out, HDMI,10MHz reference clock IN/ OUT
General Characterisitics:
Power : 100 V-240 VAC(fluctuate:±10%),50 Hz/60 Hz,100 V-120 VAC(fluctuate:±10%),400 Hz
Display : 10.1 - inch multi-touch capacitive screen, 1280*800(H*V)
Product net weight : 3.83 kg
Product size (W×H×D) : 364 mm×209 mm×106 mm
Standard quantity per carton : 1pcs
Standard Accessories
National standard cable x 1
USB3.0 cable x 1
BNC-BNC direct-through line x 1
BNC-red and black alligator connecting wire x 1
Passive probe (500 MHz/350 MHz/200 MHz) x 4
