Output: 0~30V/0~3A x2; 2.2~15V/1A x2
Output Power: 195W
Constant Voltage Operation:
Line Regulation: ≤0.01%+3mV
Load Regulation: ≤0.01%+3mV
Ripple and Noise: ≤1mVrms
Constant Current Operation:
Line Regulation: ≤0.2%+3mA
Load Regulation: ≤0.2%+3mA
Ripple and Noise: ≤3mArms
Tracking Operation:
Parallel:
Line Regulation: ≤0.01%+3mV
Load Regulation: ≤0.02%+5mV
Series:
Line Regulation: ≤0.01%+5mV
Load Regulation: ≤300mV
Auxiliary Output (CH3/CH4):
Output Voltage: 2.2V~15V
Output Current: Fixed 1A
Load Regulation: ≤25mV @ 110V/220Vac rated output
Ripple and Noise (5Hz~1MHz): ≤2.0 mVrms
Protection:
Overload Protection and Reverse Polarity Protection
Display:
Voltmeter: 3-digit LED display
Ammeter: 3-digit LED display
Resolution: 100mV/10mA
Accuracy:
Actual Voltage and Current Output: ±(1% of reading + 2 digits)
Preset Voltage and Current: ±(1% of reading + 8 digits)
General Specifications:
Protection: Overload Protection and Reverse Polarity Protection
Power Supply: AC110V, AC220V or AC110V/220V ±10%, 50/60Hz
Operating Environment: 0℃~40℃, ≤80%RH
Storage Environment: -10℃~70℃, ≤70%RH
Power Supply: Selectable AC110V/220V ±10%, 50/60Hz
Accessories: Power Cord x1, User Manual x1
Weight: 8.5kg
