Output
Phase: 1φ2W
Voltage:
Low: 1.0V–150.0V
High: 150.1V–300.0V (Auto-switching)
Frequency: 45–250Hz, step: 0.1Hz
Maximum Output Current:
At 120V: 3A
At 240V: 1.5A
Load Regulation: ≤1%
Current Stability: ≤1%
Frequency Stability: ≤0.01%
Crest Factor: 1.41 ± 0.10
Efficiency: ≥75%
Response Time: Max. 20ms
Frequency Resolution: 0.01Hz
Voltage Resolution: 0.01V
Current Resolution: 0.0001A
Power Resolution: 4-digit LED, resolution: 0.001W / 0.001kW
Power Factor Resolution: 3-digit LED, resolution: 0.01
Measurement Accuracy:
Voltage: ±0.5% of full scale + 5 digits
Current: ±0.5% of full scale + 5 digits
Frequency: ±0.01% of full scale + 5 digits
Power: ±0.5% of full scale + 5 digits
Setting Accuracy:
Voltage: ±1% of full scale
Frequency: ±0.1% of full scale
Communication Interface: RS232
Preset Function: Preset output voltage and frequency
Quick Access Keys: Quick keys for 110V, 220V, 50Hz, 60Hz
Alarm Function:
Audible and visual alarm after protection is triggered
Error codes displayed on LED screen
Protection:
Fast-response circuits for detecting over-current, overload, over-temperature, and short-circuit
Output is shut off under protection mode
Cooling: Cooling fan
Operating Environment:
Temperature: 0°C–40°C
Humidity: ≤90% RH (non-condensing)
Altitude: up to 2000 feet
Dimensions (mm): 430W × 133H × 480D
Weight: 13.5 kg
