Size Range: 0.5 to 25 μm.
Particle Size Channels: 0.5, 0.7, 1.0, 3.0, 5.0, 10 μm.
Size Resolution: <15% @ 0.5 μm (per ISO 21501-4).
Counting Efficiency: 50% at 0.5 μm; 100% for particles >0.75 μm (per ISO 21501-4 and JIS).
Viable Detection: 2 fluorescence channels and 1 size channel for classification.
Sample Collection: Integrated filter holder for 37-mm membrane filter.
Concentration Limit: 820,000 particles/ft³ (29,000,000 particles/m³) @ 10% coincidence loss.
Flow Rate: 1.0 CFM (28.3 L/min) with ±5% accuracy.
Light Source: Total particles: 660 nm laser diode; Viable particles: 405 nm laser diode (fluorescence detection).
Flow Control: Electronic, automatic closed-loop (patented technology).
Alarms: Built-in audible alarm >85 dB at 1 meter; external alarm relay.
Display: 5.7-inch (14.5-cm) VGA touchscreen.
Enclosure: Stainless steel.
Dimensions (H x W x D): 48.3 cm x 26.7 cm x 29.7 cm.
Weight: 16.8 kg (37 lbs).
Sampling Modes: Manual, automatic, beep; cumulative/differential; count or concentration.
Data Storage: 250 zones, 999 locations, and 10,000 sample records.
Languages: English, German, French, Spanish, Japanese, Chinese, Italian.
Software: TrakPro™ Lite Secure and FMS Software (OPC UA Bridge 5SP).
Data Transfer Modes:
Manual: Export .xml files via USB or Ethernet.
Automatic: Connect to FMS software via Ethernet or OPC UA.
Operating Temperature: 5°C to 30°C (41°F to 86°F).
Operating Humidity: 20% to 85% RH, non-condensing.
Maximum Altitude: 3,000 m (10,000 ft).
