Outputs (mV and pC): Impedance: mV output <50 Ω.
Level Accuracy: ±0.5% of reading ±0.1% of FS; ±3 LSD at 25°C (±0.015%/°C).
Frequencies: 61.4 Hz, 100 Hz, 140 Hz, 318 Hz, and 1000 Hz.
Frequency Accuracy: ±0.5% @ 25°C, ±0.015%/°C.
Units: DC, RMS, Pk, and Pk-Pk.
Controls – Frequency, Power: Selects desired frequency or On/Off.
Amplitude Selector: Four-digit thumb switch allows level selection of 0.1 to 9999 mV and pC.
Units Selector: Selects DC, Pk, RMS, or Pk-Pk.
DC Offset: Variable from 1 to 12 VDC.
X1–X10 Switch: In “X10” position, output level is multiplied by 10.
Indicators – Chrg On: LED illuminates when charging.
Indicators – Batt Low: LED illuminates when battery-low condition exists.
Interface – Power: 110 VAC with supplied charger; 6 VDC rechargeable batteries.
Mechanical – Dimensions: 2.5" H × 6" W × 7" L (6.3 cm × 15.2 cm × 17.8 cm).
