Specifications
Frequency Range
SK-4000-TC 85MHz-4000MHz
Frequency Accuracy ±2.5× 10-6
Output Power
SK-4000，SK-4500，SK-6000 -10dBm
SK-200 -5dBm
Reflect Amplitude Accuracy
-15dB to 0 dB 0.4dB
-25dB to -15dB 1.5dB
-35dB to -25dB 4.0dB
Trace Noise Magnitude(IFBW 1kHz) 0.02dB rms
Measurement Speed 1ms/data point.
Measurement Points 51 to 3201
Temperature Stabalility
0.01dB/ ℉
0.02dB/℃
Return Loss Measurement Range 0 dB to-60dB
Resolution 0.01dB
VSWR Measurement Range 1.0 to 65.0
Cable Loss Measurement Range 0 dB to 30 dB
DTF Range 0 to 5000(ft)
0 to 1500(m)
Test Port Connector Impedance N-type,Female 50 ohms
Connector
SK-200-TC,SK-4000-TC Micro USB B,USB 2.0
SK-4500-TC,SK-6000-TC USB Type-C,USB 3.0
Languages English,Chinese,Spanish
Recommended Calibration Interval 3 year
Dimensions(L×W×H)
SK-4000-TC,SK-200-TC 7.2×3.8×1.9(in)
182×95×46.5(mm)
SK-4500-TC，SK-6000-TC 7.7×3.6×2.4(in)
195×90×60(mm)
Weight 1.98(lbs) 0.9(kg)
Maximum Input Voltage 50V
Operates In Temperature
14 ℉ to 131 ℉
-10℃ to +55℃
Storage Temperature
-40 ℉ to 176 ℉
-40℃ to +80℃
Battery Charging Temperature
32 ℉ to 95 ℉
0℃ to +35℃
Storage Capacity Thousands of Trace and Setups
Immunity to Interfering Signals +13dBm
CE
EMC-Standard EN 61326-1:2006
Safety-Standard EN 71010-1:2001
Standard EN61000-3-2:2006+A1:2009+A2:2009
EN61000-3-3:2013
Battery（Lithium-ion rechargeable）
SK-4000-TC,SK-200-TC 4 Hrs Typical Operating Time
SK-4500-TC，SK-6000-TC 10 Hrs Typical Operating Time
Battery Charge Time 5 Hrs for Full Charge
Power Measurement Yes
Compatible With 7020,5012D,5014,5015,5015-EF,5016D,5017D,5018D,5019D
GPS SK-4500-TC,SK-6000-TC
