TRACO Power TPI 100-128A-J ຕົວແປ AC-DC 100.2W 28V 3.58A 2x3 open PS

Width: 50.8 mm (2 in)

Height: 29.5 mm (1.161 in)

Length: 76.2 mm (3 in)

Industry: Industrial

Approvals: UL60950-1, EN60950-1

Compliance: UL60950-1; EN 60950-1

Unit Weight: 156 g

Output Power: 100 W

Input Voltage: 85 VAC to 264 VAC

Mounting Style: Chassis

Input Frequency: 47 Hz to 63 Hz

Load Regulation: Regulated

Isolation Voltage: 3000 Vrms

Number of Outputs: 1 Output

Open Frame/Enclosed: Open Frame

Output Current-Channel 1: 3.58 A

Output Voltage-Channel 1: 28 VDC

Operating Temperature Range: - 40 C to + 80 C

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 40 C
