Shutdown: No Shutdown
Topology: Single
Input Type: Differential
Technology: CMOS
Unit Weight: 7 mg
Amplifier Type: Low Noise
Mounting Style: SMD/SMT
SR - Slew Rate: 1 V/us
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.2 V
Ib - Input Bias Current: 1 pA
Operating Supply Current: 500 uA
Vcm - Common Mode Voltage: 0 V to 2.4 V
Ios - Input Offset Current: 1 pA
Output Current per Channel: 1.5 mA
Vos - Input Offset Voltage: 1 mV
Maximum Dual Supply Voltage: +/- 2.75 V
Minimum Dual Supply Voltage: +/- 1.1 V
GBP - Gain Bandwidth Product: 3.5 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 7.8 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 80 dB
PSRR - Power Supply Rejection Ratio: 80 dB
