Fall Time: 7 ns
Rise Time: 9 ns
Technology: Si
Unit Weight: 6.600 mg
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 3.2 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 1.8 W
Vgs - Gate-Source Voltage: - 20 V, + 10 V
Typical Turn-On Delay Time: 21 ns
Typical Turn-Off Delay Time: 16 ns
Id - Continuous Drain Current: 3.5 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 69 mOhms
Vds - Drain-Source Breakdown Voltage: 100 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
