Tormach xsTECH Pro ເຄື່ອງ CNC Router
Travels: X-Axis: 10.2 in. (259 mm); Y-Axis: 9.3 in. (237 mm); Z-Axis: 6.3 in. (160 mm).
Note: *X travel is 12.3 in. (312 mm) without tool changer.
Spindle Power: 350W.
Maximum Speed: 20,000 RPM.
Spindle Taper: ISO 10.
Spindle Runout: < 0.0008 in. / 0.02 mm.
Resolution: 0.0002 in. / 0.005 mm.
Repeatability: ±0.001 in. / ±0.025 mm.
Safety Certifications: UL, CE.
Power Required: USA, Mexico, Canada: 120V, 15A Breaker; Europe: 230V, 6A Breaker.
Air Required: 90 – 120 psi.
Work Area: 12 in. × 9 in. × 6.5 in. (X, Y, Z).
System Footprint: 22.5 in. × 23.6 in. × 26.4 in. (570 mm × 600 mm × 670 mm).
Installation Requirement: Can fit on a 24 in. countertop.
Overall System Height: 27 in. (685.8 mm).
System Weight: 150 lbs. (68 kg).
