Tormach 24R ເຄື່ອງ CNC Router
Travels: X-Axis: 24.75 in. (625 mm); Y-Axis: 55.75 in. (1415 mm); Z-Axis: 6.70 in. (170 mm)
Spindle Power: 2 hp / 1.5 kW
Spindle Type: Electrospindle
Minimum Speed: 10,000 RPM
Maximum Speed: 24,000 RPM
Cooling: Water-Cooled (Chiller Included)
Spindle Taper: Stock - ER20; With ATC - ISO20
Thread Machining: Thread Mill
Power Required: 24R CNC Router: Single-Phase 115 VAC, 50/60 Hz, 15A Breaker
Power Required for Storm Vacuum Pump: Single-Phase 220-240 VAC, 20A Breaker
Table Type: Integrated Vacuum Table
Table Size: 26.5 in. × 65 in. (680 mm × 1650 mm)
Gantry Clearance: 6 in. (154 mm)
Machine Footprint: 72 in. × 39 in. (1.8 m × 1 m)
Overall System Height: 76.5 in. (1.9 m)
Typical System Weight: 900 lb (408 kg)
Axis Motion: Ballscrew and Stepper Driver
Guideways: Precision Linear Guideway
Maximum Feed Rate: 200 IPM (5.0 m/min)
Stand: Welded Steel (Included)
Machine Base: Cast Iron
Gantry: Aluminum
Resolution: 0.00025 in. (0.006 mm)
Ball Screw Positional Accuracy: ±0.002 in./ft. (±0.167 mm/m)
Repeatability: ±0.001 in. (±0.02 mm)
Certificate of Inspection: Available
PATHPILOT® Controller: Easy-to-learn, touch-screen-friendly user interface
Axis Support: Supports up to four-axis continuous machining
Programming: Intuitive conversational programming
Speeds and Feeds Calculator: Built-in recommended speeds and feeds calculator
Program Memory: 80GB
Software Updates: Free PathPilot® updates for life
