Tonghui TH6422A Linear Programmable DC Power Supply (0-32V / 0-3A)
Rated Output (0℃-40℃):
Voltage/Current/Power
CH1: 0-32V, 0-3A, 96W
CH2: 0-32V, 0-3A, 96W
CH3: 0-5V, 0-3A, 15W
Load regulation ± (% Output + Bias):
- Voltage: ≤0.01% + 3 mV
- Current: ≤0.2% + 3 mA
Power regulation ± (% Output + Bias):
- Voltage: ≤0.01% + 3 mV
- Current: ≤0.2% + 3 mA
Programming resolution:
- Voltage: 10mV
- Current: 10mA
Read-back value resolution:
- Voltage: 10mV
- Current: 10mA
- Programming Accuracy (25℃±5℃):
+ Voltage: ±(0.1% of reading + 30mV)
+ Current: ±(0.5% of reading + 30mA)
- Readback value Accuracy (25℃±5℃):
+ Voltage: ±(0.1% of reading + 30mV)
+ Current: ±(0.5% of reading + 30mV)
Ripple and Noise (20Hz-20MHz):
+ Voltage (Vp-p): ≤3mVp-p
+ Voltage (rms): ≤1mVrms
+ Current: ≤3mArms
Parallel Programming Accuracy:
Voltage: ±(0.1% of reading + 30mV)
Current: ±(0.5% of reading + 30mA)
Timer: 0.1 ~ 99999 seconds
Memory: 5 Groups and 1 goup of automatic memory when power off
Size（W×H×D）mm: 215×133×268
Weight（kg): 4.7 kg
