Test Parameters: |Z|, |Y|, C, L, X, B, R, G, D, Q, θ, ESR , Rp ; 22 parameter combinations available
Range:
- Mode: Auto, Hold, Manual
- Subsection 9 sects: 10Ω, 30Ω, 100Ω, 300Ω, 1kΩ, 3kΩ, 10kΩ, 30kΩ, 100kΩ
Display: 320×240 dot-matrix graphic LCD display
Signal Frequency: 20 Hz − 1MHz 6000 selectable frequencies
Accuracy: 0.01%
Output Impedance: 30 Ω and 100 Ω selectable
Measurement Display Range:
|Z|, R, X: 0. 01mΩ — 99.9999MΩ
|Y|, G, B: 0. 01nS — 99.9999S
C: 0. 00001pF — 9.99999F
L: 0.01nH — 99.9999kH
D: 0.00001 — 9.99999
Q: 0.01 — 99999.9
θ: ( DEG) -179.999º — 179.999 º
θ: ( RAD) -3.14159 — 3.14159
Δ%: -999.999% — 999.999%
Operation Temperature And Humidity: 0°C − 40°C, ≤ 90%RH
Power Requirements:
- Voltage: 99V−121V AC,198V−242V AC
- Frequency: 47.5Hz − 63Hz
Power Consumption: ≤ 100VA
Dimensions (W×H×D): 430mm×185mm×490mm
Weight: Approx. 15 kg
Instrument Accessories
- TH26005C 4 terminal test fixture
- TH26011B 4 terminal pair Kelvin test clip leads
- TH26010 Gilded shorting plate
- TH10002 GPIB interface board (only TH2828S)
- TH26025 USB interface board (only TH2828S)
- TH26026 2GB USB disk (only TH2828S)
Options
- TH26047 4 terminal test fixture
- TH26048 4 terminal test fixture
- TH26006 Axial component test module
- TH26007A Core inductor test fixture
- TH26008A SMD component test fixture
- TH26009B SMD Kelvin test tweezers
- TH10301 20Vrms/40V DC power amplifier/DC bias board
- TH10401 2m/4m cable length operation
- TH10002 GPIB interface board
- TH10202 Handler/Scanner interface board
- TH12019 TH2828 RS232C control software
- TH12020 TH2828A RS232C control software
