Test frequency: 20Hz–5MHz with resolution of 10mHz
Measurement Parameters: C, L, R,Z,Y,X,B, G, D, Q, θ, DCR
Test Level
- f≤1MHz: 10mV–5V,±(10%+10mV)
- f>1MHz: 10mV–1V,±(20%+10mV)
Output impedance: 10Ω, 30Ω, 50Ω, 100Ω
Basic Accuracy: 0.1%
Display Range:
- L: 0.0001 uH – 9.9999kH
- C: 0.0001 pF – 9.9999F
- R,X,Z,DCR: 0.0001 Ω – 99.999 MΩ
- Y, B, G: 0.0001 nS – 99.999 S
- D: 0.0001 – 9.9999
- Q: 0.0001 – 99999
- Θ: -179.99° – 179.99°
Measuring Speed(meas/sec): Fast: 200(f>30kHz),100(f>1kHz)Med: 25, Slow: 5
Calibration function: Open/Shot /load
Equivalent mode: Serial, Parallel
Ranging Mode: Auto and Hold
Display Mode: Direct, ABS, Rel
Trigger Mode: Internal, Manual, External, BUS
Internal DC bias source:
- Voltage mode -5V – +5V,±(10%+10mV), with the resolution of 1mV
- Current mode(internal resistance is50Ω) -100mA – +100mA, ±(10%+0.2mA), with the resolution of 20uA
Comparator function: bins and bin counters
Display: 320×240 dot-matrix LCD display
Memory groups of control settings can be saved
Interface:
- USB DEVICE( USBTMC and USBCDC support)
- USB HOST(FAT16 and FAT32 support)
- LAN(LXI class C support)
- RS232C
- HANDLER
- GPIB(option)
Working Temperature & Humidity: 0°C − 40°C, ≤90%RH
Power supply:
- Voltage: 99V−121V,198V−242V
- Frequency: 47.5Hz−63Hz
Power Consumption: ≤ 80VA
Dimensions (W×H×D): 400mmx132mmx385mm
Weight: Approx. 10kg
