Test Parameter: L-Q, C-D, R-Q, Z|-Q
Basic Accuracy: 0.1%
Equivalents Circuit: Series, parallel
Mathematical Functions: Deviation and Percent Deviation
Trigger Mode: Internal, Manual and External
Measurement Speed: Fast: 12, Med: 5.1, Slow: 2.5 (meas/ sec)
Measurement Terminals: Five Terminals
Test Frequency: 100Hz,120Hz,1kHz,10kHz, Accuracy 0.01%
Measurement Display Range:
- |Z|, R: 0.1mΩ - 99.99MΩ
- C:
100Hz/120Hz 1pF - 99999μ F
1kHz 0.1pF - 9999.9μ F
10kHz 0.01pF - 999.99μ F
- L:
100Hz/120Hz 1µH - 99999H
1kHz 0.1µH - 9999.9H
10kHz 0.01µH - 999.99H
- D: 0.0001 - 9.999
- Q: 0.0001 - 9999
- Δ%: -999.99% - 999.99%
Operation Temperature & Humidity: 0°C - 40°C, ≤90%RH
Power Requirements:
- Voltage: 99V - 121V, 198V - 242V
- Frequency: 47.5Hz - 63Hz
Power Consumption: ≤20 VA
Dimensions (W×H×D): 270mmx130mmx300mm
Weight: Approx. 3.7kg
Instrument Accessories
TH26001A 4 terminal test fixture
TH26004-1 4 terminal Kelvin test clip leads
TH26010 Gilded shorting plate
Options
TH26005A 4 terminal test fixture
TH26006 Axial component test module
TH26007A Core inductor test fixture
TH26008A SMD component test fixture
TH26009B SMD Kelvin test tweezers
TH26029B SMD Kelvin test tweezers
TH26011A 4 terminal Kelvin test clip leads
