Dimension: L1800 * W1300 * H1200mm
Weight:About 1.2T
Power supply: 3PH 380V，50HZ,
Voltage fluctuation range: +8% ～ –8%；
start total power: 10KW
Compressed air:After drying, filtration and stabilivolt: outlet pressure＞ 5.0kg/cm2
Suitable system: Lithium iron phosphate, lithium cobalt oxide, lithium manganese oxide, graphite and silicon carbon system battery positive and negative electrode coating process
Coating method:Continuous coating, interval coating
Oven section number: 1 section 1 meter oven
Substrate thickness: Aluminum foil：8 ～ 30um；Copper foil：8 ～ 30um
Roll surface design width: 330mm
Ensure coating width: ≤ 280mm
Coating: ± 3um
Double-sided coating weight accuracy (mg/cm2):Coating center value ±1.0%
Slurry viscosity: 2000 ~ 12000 (mPas)
Single-coated dry thickness range: 20-200μm
Solvent characteristics
Oily solvent NMP(s.g=1.033,b.p=204℃)
Watery solvent H2O/NMP(s.g=1.000,b.p=100℃)
Solid content: 20 ~ 85%
Coating dimension accuracy(mm): L ≤ ±1、W ≤ ±0.5
Positive and negative alignment accuracy(mm): L≤±1、W≤±0.5
