Working Voltage: 110-220V AC, 50/60Hz, Single Phase
Glove Box Chamber
Case Material: Stainless Steel 304 with 3mm thickness
Dimensions: 1220mm(L) x 760mm(W) x 900mm(H)
Removable Front Window Panel
Chamber Condition
Water concentration: <1 ppm (20°C, 1 atm)
Oxygen concentration: <1 ppm (20°C, 1 atm)
Leak rate: <0.05 Vol% / hr (Depending on oxygen concentration inside the glove box)
Air-lock Chamber
Antechamber Dimensions: 360mm(Dia.) x 600mm(L)
Small Chamber Dimensions (for tools): 150 mm(Dia.) x 300mm(L)
Working Gas
Operating gas: Inert gas such as N2, Ar, He
Regenerating gas: Mixture of H2 (5-10%) and Operating gas
For purification system with only water adsorbing function,
Regenerating gas will be the same as Operating gas
Gas Purification System
Automated Regeneration Process
Automated water and oxygen removal
Filter System: Inlet and Outlet filter can eliminate particle size > 0.3μm
Pressure Control System
Automatic pressure control by PLC for the Glove Box Chamber
Pressure Range: +/- 12mbar
Manual pressure control is allowed via a foot pedal
Purging System: Automatic Purging System allows easy operating and reduce gas consumption
Control system
Siemens PLC control system with 6" touch screen display
Water concentration: 0 - 1000 ppm with an accuracy of 0.1 ppm
Oxygen concentration: 0 - 1000 ppm with an accuracy of 0.1 ppm
Pressure: -2500 to 2500 Pa with an accuracy of 1 Pa
Data: Automatic system data logging
Pump: England RV-8 EDWARDS pump is included for faster vacuum and removing moisture
Vacuum rate: 8 m^3/hr
Purification Pipeline: 304 Stainless Steel, KF40 and KF25 Port
Gloves: A pair of 9 3/4" butyl glove is included for immediate use
Lighting: Built in fluorescent lamp
Product Dimensions: 2300mm(L) x 1500mm(W) x 1900mm(H) (91" x 59" x 75")
