TOB TOB-JL-1177 ເຄື່ອງວິເຄາະຂະໜາດອະນຸພາກເລເຊີ (0.02μm～2000μm,2min/sample)

Voltage supply: AC 110V/220V 50HZ/60HZ±10%

Power: 300W

Measuring range: 0.02μm～2000μm, full automatic measure

Measure principle : Scattering, diffraction principle,

the Mie scattering theory (Mie) calculations and proprietary technology.

Sampling mode: Wet, circular sample system, the sample pool volume 500mL

Repeatability error: 1%

Testing time: 2min/sample

Laser wavelength : 0.6328um

Interface mode: RS232 Serial port

Working environment: Temperature : 5～35℃ Humidity : ＜85%

Dimension(L*W*H): 840*380*520mm

Net weight: About 70kg

Datasheet

Instrument characteristics

1, The instrument integrates optical, circuit, sample pool, ultrasonic dispersing, mixing cycle, automatic cleaning integration, computer control automatic centering.

2, Test software interface is friendly, simple operation, full automatic

3, With six different report formats, including the cumulative particle size distribution data and curve, the interval size distribution histogram, data and typical particle size values such as D3, D10, D25, D50, D75, D84, D90, D97, the average particle size data.
