TOB TOB-IT8512 DC Programmable Electronic Load (120V/30A/300W)
Input Rating
Power: 300W
Current: 0-30A
Voltage: 0-120V
CC Mode
Range: 0-3A0-30A
Resolution: 0.1mA1mA
Accuracy: 0.05%+0.1%FS0.1%+0.1%FS
CV Mode
Range: 0.1-18V0.1-120V
Resolution: 1mV10mV
Accuracy: 0.05%+0.02%FS0.05%+0.025%FS
CR Mode
Range: 0.1-99Ω100-4KΩ
Resolution: 0.01Ω1Ω
Accuracy: 1%+0.3%FS1%+0.8%FS
CW Mode
Range: 0-100W100-300W
Resolution: 1mW10mW
Accuracy: 1%+0.1%FS1%+0.1%FS
Voltage Measurement
Voltage: 0-18V0-120V
Resolution: 1mV10mV
Accuracy: 0.02% + 0.02%FS0.02% + 0.025%FS
Current Measurement
Current: 0-3A0-30A
Resolution: 0.1mA1mA
Accuracy: 0.1% + 0.1%FS0.2% + 0.15%FS
Battery Test: Battery Input:0.1-120V; Max.Measurement:Capacity=999AH
Dynamic Test: Transition List:0-1kHZ
Short Circuit
Current(CC): =3A=30A
Voltage(CV): 0V
Resistance(CR): =40mOh
Temperature
Operating: 0~40oC
Nonoperating: -10oC~70oC
DimensionW*H*D(mm): 214*88*354mm
Weight Kg: 3.5
