Input Power: AC 220V ±10% / 50Hz (AC110V/60HZ)
Resolution: AD：16bit；DA：16bit
Input Resistance: ≥1MΩ
Input Power: 2127W
Channel Features: Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure
Channel Control Mode: Independent Control
Voltage
Per Channel Voltage Range: Charge: 25mV~5V；Discharge：25mV~5V
Discharge Min Voltage: 2.5V
Accuracy: ± 0.05% of FS
Stability: ± 0.05% of FS
Current
Per Channel Current Range: Charge：150mA~30A；Discharge：150mA~30A
Accuracy: ± 0.05% of FS
Stability: ± 0.05% of FS
Power
Per Channel Output Power: 150W
Stability: ± 0.1% of FS
Time
Current Response Time: 1ms (0-Full Range)
Step Time Range: ≤(365*24 )hour/step，Time Form Support 00：00：00(h、min:s、ms)
Data Recording
Record Condition
Lower sampling time：100ms
Lower sampling Voltage：5mV
Lower sampling Current：30mA
Record Frequency : 10Hz
Charge
Charge Mode: Constant Current Charge、Constant Voltage Charge、Constant Current and Constant Voltage Charge、CPC
End Conditon: Voltage、Current、Relative Time、Capacity
Discharge
Discharge Mode: CCD、CPD、CRD
End Condition: Voltage、Current、Relative Time、Capacity、
Pulse
Charge: CCC
Discharge: CCD
Min Pulse Width: 500ms
Automated Switch: Automated swith from charge to discharge for each pulse
End Condition: Voltage, Test Time
Cycle
Loop Measure Range: 1~65535 times
Max Steps Per Loop : 254
Nested Loop: Nested loop Function，Max Support 3 Layers
Protection
Software Protection
Power-down Data Protection
Off-line Testing Function
Setting Protection Condition，Setting Parameter： Low Voltage limit、Upper Voltage limit、Low Current limit、Upper Current limit、Delay Time
Hardware Protection: Additional Anti-reverse Protection Model
Voltage and Current Testing Sample: 4-wire connecting
Noise: <85dB
Database: MySQL Database
A Means of Communication of Upper Machine: TCP/IP Protocol
Data Output: EXCEL、TXT、Graph
Communication Interface: Ethernet Port
Per Unit Main Channels No.: 8
Dimensions: 12U，482*508*378(mm)
