TOB TOB-BK-3512L/2 ການສ້າງແບດເຕີລີ່ແລະເຄື່ອງທົດສອບລະດັບ (512 Channels, 5V2A)
Source voltage: AC380v, 50hz
Power: 9kw
Dimension: 1600×500×1840mm
Channel: 512
Control mode: Total control
Charging mode: Constant current,constant voltage
Charge cut-off condition: Voltage, current, time, capacity
Discharge mode: Constant current
Discharge cut-off mode: Voltage, time, Capacity
Protect function
Over voltage, under voltage, over current, under current, over capacity
Reverse connect protection
Power-off protection, data breakpoints recovery
Work flow setting: 32 step with 256 cycles
Sampling inspection cycle: ≤8s
Minimum frequency of data recording: ≤8s
Channel parameter
Voltage testing range: 0-5v, resolution 1mV
Battery voltage range: Charging :0-4.5V, Discharging :4.5-2V
Constant voltage range: 2-4.5V
Voltage accuracy: ±(0.1%RD+0.1%FS)
Current range: Charging :0.01-2A, Discharging :0.01-2A,resolution 1mA
Current accuracy: ±(0.1%RD+0.1%FS)
Time range: 0-30000min can be set,
Suitable battery height: 10~80mm
Fixture spacing: 35m
