Source voltage: AC220V/50Hz/Single phase. Customized according country request
Power: 3.8KW
Compressed air: 0.4～0.6Mpa
Suitable battery size: According to customer’s requirement
Operating environment
Temperature : 20～35℃
Humidity: 5～55％HR
Material
Electrode
Feeding mode: Roller
Material width(mm): 100-200
Material thickness(um): 100-280
Material thickness(mm): Ф360
Inner diameter(mm): Ф76.2
Separator
Feeding mode: Roller
Material width(mm): 100-200
Material thickness(um): 16-25
Material thickness(mm): Ф280
Inner diameter(mm): Ф76.2
Tape
Feeding mode: Roller
Material width(mm): 20-60
Material thickness(um): 20-50
Material thickness(mm): Ф150
Inner diameter(mm): Ф76.2
Winding accuracy: 0.5mm
Winding error: 0.3mm
Separator tension: 0.05-0.5kg
Electrode tension: 0.05-0.5kg
Output: 4-7PPm
Dimension (L*W*H): 2400*1300*2000mm
Weight: 1200kg
