TOB TOB-AT526 ອຸປະກອນການທົດສອບຄວາມຕ້ານທານຫມໍ້ໄຟສໍາລັບການທົດສອບ Supercapacitot ESR (0-120V,0.001mΩ~33kΩ)
Test parameters: AC resistance, DC voltage
Basic accuracy
Resistance: 0.2%
Voltage: 0.01%
Measuring range
Resistance: 0.001mΩ ~33.000kΩ
Voltage: 0.00001V~120.000VDC
Signal source: AC 1kHz, test current: <150ma
Range: Seven range auto and manual
Test speed: 145 times/second, 30 times/second, 10 times /second,1 times/second
Display results: Direct reading,ΔABS,Δ%,θ,to sorting results
Correction: Full range short circuit reset
Comparator: Optional 18 sorting RHI/RNG/RLO output VHI/VNG/VLO outputThe absolute value of tolerance ±TOL Sorting percentage tolerance TOL sorting Sequential sorting
Trigger: Internal trigger, manual trigger, external trigger and remote trigger
Interface: RS-232C interface handler interface (PLC interface)
Power requirement: Voltage: 195vac ~ 245vac frequency: 50Hz power: maximum 15va
Size and weight: External dimensions (mm):264 (W) x107 (high) x350 (deep) weight: 4kg
Appendix: ATL502 Kelvin test line,ATL108/ RS232 interface cable
Others: Test line damage detection , color TFT-LCD display, keyboard lock and data hold function, internal flash memory and disk data recording
