TLP HHL-20 ເຄື່ອງດຶງໄຮໂດຼລິກແບບບັນຈຸເອງ (20T)

Output: 20 ton

Spread: 100–350 mm

Max reach: 205 mm

Ram stroke: 70 mm

Dimensions (E/F/G/A/B/C): 78 / 33 / 105 / 21 / 33.5 / 33 mm

Weight: 18.6 kg

Packing size: 44 × 35 × 13 cm

Characteristics:

These tools are designed for removing a wide variety of gears, bearings, bushings, pulleys and other press-fitted parts.

Working pressure: 700bar

●Use with 2 or 3 jaws.

●High quality,forged steel jaws and crosshead provide superior

reliability and service.

●Precise hydraulic control allows fast,efficient and safe pulling.

●High force hydraulic system for effortless pulling of large components.

●More efficent pulling,as one man can do the job where manual pullers ofter require two operators.

●Spring loaded live centering cone. 5,10 and 20 ton sets all contained in a plastic carry case. 30 and 50 ton sets all contained in a robust wooden box.
