Test Currents: 1 mA, 10 mA, 100 mA, 1 A. Each current may be continuously adjustable from 0 to 100%.
Resistance ranges:
0-2 Ω @ 1 A.
0-20 Ω @ 100 mA.
0-200 Ω @ 10 mA.
0-2000 Ω @ 1 mA.
Resolution: 0.01 mΩ @ 1 A.
Output Voltage: Up to 10 VDC (open circuit) @ 1 A.
Measurement Principle: 4-terminal, Kelvin-type.
Basic Accuracy: ± 0.2% of reading ± 2 digits.
Advanced Features: Digital direct reading of low resistances in the alphanumerical display, with up to 4½ digits. Very fast and accurate measurements.
Serial Data Output: RS232 @ 4800 bps. Suitable for data collection in an external serial printer, computer or data-logger.
Environmental Protection: IP54 with closed lid.
Safety Class: Meets the requirements of IEC 61010-1.
Power Supply: Internal rechargeable 12 V - 3000 mAh battery or mains
Built-In Battery Charger: For 100 - 240 V~ mains supply
Operating Temperature Range: 23°F to 122°F (-5°C to 50°C).
Storage Temperature Range: -13°F to 149°F (-25°C to 65°C).
Humidity Range: 95% RH (non condensing).
Equipment Weight: Approx. 6.6 lb (3 kg).
Dimensions: 10.16” x 8.07” x 4.72” (258 x 205 x 120 mm).
Included Accessories
2 Combined current and potential test leads.
1 Power cord.
1 RS232 cable.
1 User guide.
1 Synthetic bag
