Frequency Range 4Hz to 40Hz in increments of 0.1Hz
Detector Bandwidth 0.5Hz
Sensitivity Electrostatic input: 1μV RMS for full scale deflection Auxiliary input: 0μV RMS for full scale deflection
Input Impedance Electrostatic Input: Balanced low impedance Auxiliary input: 10kΩ
Auxiliary Input Connector 7 way DIN socket
Electrostatic Input Connector 4mm binding post terminals
Power Built-in rechargeable batteries - typically 5 hours continuous use. External Extended battery connection
Mains Supply Single phase 115V AC to 240V AC
Analogue Display Analogue signal strength meter with battery and signal test
GPS Location Detection via Inbuilt GPS 4M accuracy
LCD Colour LCD with current and historical data, Day/ Night mode
Event marker Stored digitally storing Lon,Lat, and signal strength, plus comment
Detection Range Electrostatic Input: Typically 180 metres but depths of 300 metres are possible. Limited by external factors such as: signal to noise ratio, attenuation of the signal in the cable and lateral distance at which the ship is operating away from the cable Magnetic Detector Inpu: Typically 20 metres but may be limited by external factors such as signal to noise ratio and attenuation of signal in the cable
Case Type
Dimensions 470mm x 360mm x 175mm
Weight Approximately 18Kg
