Test Current: Max. 200A (True Dc). Increment 1A. Adjustable And Presetable From 0 To 100%
Resistance Ranges:
0-199.9 Μw (Test Current: Up To 200A)
0-1.999 Mw (Test Current: Up To 200A)
0-19.99 Mw (Test Current: Up To 100A)
0-199.9 Mw (Test Current: Up To 20A)
0-1999 Mw (Test Current: Up To 2A).
Reading Resolution:
0.1 Μw For R < 200 Μw
1 Μw For R < 2000 Μw
10 Μw For R < 20 Mw
Output Voltage: 4..5 Vdc @ All Currents
Display: 4 Digits Result, Current And Time
Lcd: 9Mm Character Height With Backlight
Total Resistance:
Max. 20 Mw@ 200A
Max. 40 Mw@ 100A
Measurement Principle: Four-Terminal Due To Kelvin
Thermal Protection: Protects The Instrument From Overheating
Basis Accuracy: ± 0.3% Of Reading ± 0.1% Of Range
Current Flow Duration: The Duration (Time) For Current Flow Is Limited To 3S At 200A! At Lower Currents Measuring Time Can Be Increased (E.G. 30S At 10A)
Advanced Features: Digital Direct Reading Of Resistance, Current, Measuring Time And Updated Evey Second
Built-In Memory: Storage Of 1000 Test Readings
Interface: Rs232 @ 2400, 4800, 9600 Baud., Usb-B
Environmental Protections: Ip54 (With Closed Lid)
Safety Class : Meets The Requirements Of Iec 61010-1:1990, Iec 61010-1:1992 Amendment 2
Power Supply: 90~264 Vac / 47..63Hz Single Phase
Operating Temperature: 0°C To 45°C (Battery Limited)
Storage Temperature: -10°C To 55°C (Battery Limited)
Humidity Range: 95% Of Rh (Non Condensing)
Equipment Weight: Approx. 12Kg
Dimensions: 410W X 330D X 180Hmm
Printer: Thermal Printer
