TIME TH300 ເຄື່ອງທົດສອບຄວາມແຂງຂອງ Rockwell (98.07n/10kgf)
Hardness scales: Rockwell A, B, C,D,E,F, G, H, K ,L, M ,P, R, S, V
Resolution: 0.1Rockwell unit
Pre-load: 98.07n/10kgf
Total load: 588.4n/60kgf, 980.7n/100kgf, 1471n/150kgf
Display: Matrix backlight LCD
Language: English, French, Germany
Operation: Menu selectable, Membrane keypad
Test process: Automatic
Load duration: 2-50 seconds, can be set, dynamic displayed and stored
Functions:
Upper / lower hardness limits setting and alarming
Data statistics: Ave., Max., Min., standard Deviation
Convert tested values to HB, HV, HLD and δb (Tensile-strength)
Curvature correction: cylinder and sphere surface
Data output: RS232
Tester standard: ISO6508.2, ASTM E-18
Testing space:
Vertical: 250mm (9.85”)
Horizontal: 150mm (5.91”)
Work piece size:
External surface cylinder: Min.Ø3mm (0.120”)
Internal surface cylinder: Min.Ø23mm (0.900”)
Power supply: 220v/110v, 50Hz, 4A
Dimensions (mm): 715×225×790
Weight (kg): 100
Standard Delivery
Main unit
Test block B
Test block C
120° cone diamond indenter
1/16" (1.5875mm) ball indenter
1/16" (1.5875mm) spare ball
Screw for indenter
Round flat anvil Ø70
Large vee anvil
Power supply cable
Instruction manual
Optional Accessory
Mini-printer TA230
Data communicating cable
Short diamond indenter
Flat diamond indenter
Slim diamond indenter
1/8"(Ø3.175mm) indenter and spare ball
1/4"(Ø6.350mm) indenter and spare ball
1/2"(Ø12.70mm) indenter and spare ball
Round flat anvil Ø225
Round flat anvil Ø150
Small vee anvil
Flat /vee anvil
Assistant support
Assistant joist
