Test Force:
612.9n(62.5kgf), 980.7n(100kgf), 1226n(125kgf), 1839n(187.5kgf), 2452n(250kgf), 4903n(500kgf), 7355n(750kgf), 9807n(1000kgf), 14710n(1500kgf), 29420n(3000kgf)
Test Range: 3.18~653HBW
Loading Method: Automatic (Loading/Dwell/Unloading)
Hardness Reading: Touch Screen Display
Conversion Scale:
HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15n, HR30n, HR45n, HR15T, HR30T, HR45T, HS
Data Output: Built-in Printer, RS232 Interface
Shifting between Objective and Indenter: Automatic Recognition and Shifting (Three Indenters, Two Objectives)
Total Magnification: 20×, 40×
Resolution: 1.25μm, 0.625μm
Dwell Time: 0~60s
Max. Height of Specimen: 260mm
Throat: 150mm
Power Supply: AC220V, 50Hz
Execute Standard:
ISO 6506, ASTM E10-12, jIS Z2243, GB/T 231.2
Dimension: 535×260×890mm
Packing Dimension: 820×460×1170mm
Weight (kg)
net Weight: 150
Gross Weight: 180
Standard Delivery
Main unit
20× Digital Measuring Eyepiece
1×, 2× Objective
Ф2.5mm, Ф5mm, Ф10mm Ball Indenter
Small Plane Test Table
Large Plane Test Table
V-shaped Test Table
Power Cable
Hardness Block 150~250 HBW 10/3000
Hardness Block 150~250 HBW 5/750
2x Fuse 2A
Inner Hexagon Spanner 3mm
Anti-dust Cover
Usage Instruction Manual
