Technical Specification
Operating temperature: -10℃~+50℃
Storage temperature: -20℃~+60℃
Language: English/Chinese/Spanish selectable
Probe socket: LEMO or BNC
Battery (mAh): 2x3.7V 5000mAh
Battery working time: >8h
Charging time (h): <8h
Power adapter
Input: 100-240~50/60Hz
Output: 9V DC/3A~4A
LCD: Color transmission TFT, 640x480
Dimension (mm): 177X255X51
Weight (g): 1200
Basic
Measuring unit: mm/inch/μs
Scanning range (mm): 0-10000
Sound velocity (m/s): 600-16000
P-delay (μs): -1.000~750.000
D-delay (μs): -20~+3400
Test mode: Pulse-echo, dual and through transmission
Scanning mode: A scan and B scan, displaying both simultaneously
Pulse generator
Pulser (V): Square pulse
Transmitting voltage: 100~400(V) variable in steps of 10V
Transmitting pulse width (ns): 75/100~500 variable in steps of 50ns
Damping (Ω): 50/100/200/500
Pulse repetition frequency (Hz): 10~1000
Receiver
Gain (dB): 0~110
Bandwidth (MHz): 0.5~15
Rectify: Positive half wave, negative half wave, full and RF
Vertical linearity accuracy: ±2%
Amplifier resolution (dB): ±1
Rejection (%): Linear, 0~80% of the full screen
Sampling frequency (MHz): 80
Crosstalk rejection (dB): ≥80
Dead zone (μs): ≤10 (related with transmitting)
Dynamic range (dB): ≥40
Instant resolution (dB): ≥32
Time base linearity: <±0.2% full screen
Sensitivity leavings (dB): ≥62
Measurements and others
Gate: 2 indepent gates
Testing position: Edge, Peak value
Gate measurements: Echo amplitude, Sound path, depth, projection etc.
Freeze: Freeze waveform, peak value, comparative and envelope
AVG equivalent calculate: Calculate the flaw equivalent according to the flaw echo and AVG curve
DAC flaw evaluating: Make flaw evaluation according to flaw echo and DAC curve
Gate logic: Off, measurement, gate positive wave alarm, gate negative wave alarm
Gate alarm: off, anytime, hold for 0.2s, 0.5s, 1s and 2s, lock
Alarm: on/off
Data management, communication and print
Data storage
Data management:
50 channels
1000 wave images (including 980 A scan images and 20 B scan images)
4x2000 dynamic wave image
Store, review or replay the channels, waves
All the data can be stored to PC or flash disk
Communication: Communicate with PC via USB interface
Printing: Print report
Outout port
USB OTG port: USB 2.0 device connected with PC
USB 2.0 host connected with flash disk
