THORLABS S3FC405 ແຫຼ່ງ FP Laser ກັບ TEC (405 nm)
Wavelength Minimum: 395 nm
Wavelength Typical: 405 nm
Wavelength Maximum: 415 nm
Full Output Power:
- Minimum: 2.0 mW
- Typical: 6.0 mW
Laser Class: 3B
Fiber: S405
Output Fiber Connector: FC/PC, Wide 2.1 mm Key Compatible
Driver
- Power Stability: 15 min: ±0.05 dB, 24 hr: ±0.1 dB (After 1 hr Warm-up at 25 ± 10 °C Ambient)
- Display Accuracy (mW): ±10% of Actual
- Setpoint Resolution: 0.01 mW
- Adjustment Range: ~0 mW to Full Power
TEC
- Stability: 0.005 °C / 1 °C
- Setpoint Accuracy: ±0.25 °C
- Setpoint Resolution: ±0.1 °C
- Adjustment Range: 20 ± 1 °C to 30 ± 1 °C
Environmental:
- Operating Temperature: 15 to 35°C
- Storage Temperature: 0 to 50 °C
Input Power: 115/230 VAC (Switch Selectable), 50 - 60 Hz
Modulation Input:0 - 5 V = 0 - Full Power, DC or Sine wave Input Only
Modulation Input Impedance: 50 Ω
Modulation Bandwidth
- 5 kHz Full Depth of Modulation
- 30 kHz Small Signal Modulation
