Electrical Characteristics
Adjustable Output Voltage: 0 to ±25 V RMS
Voltage Resolution: 1.0 mV
Adjustable Output Frequency: 500 Hz to 10 kHz, 50% Duty Square Wave
Adjustable Internal Switching Frequency: 0.1 Hz to 150 Hz at 50% Duty Cycle
Slew Rate: 10 V/µs
DC Offset: ±10 mV
Warm Up Time: 30 Minutes
USB Port: USB 3.0 Micro B
K-Cube Controller Hub Connector: 26-Way ERNI
Maximum Ratings
Maximum External Input Voltage: 5 VDC
Maximum External Modulation: 150 Hz
Maximum Output Current: 50 mA
Operating Temperature Range: 10 to 40°C
Maximum Relative Humidity: 85%
Input Power Requirements
Voltage (Current) +15 V (220 mA), -15 V (50 mA), +5 V (350 mA)
General
Weight: 140 g (5.0 oz)
Housing Dimensions (W x D x H)(a): 60.0 mm x 60.0 mm x 46.7 mm (2.36" x 2.36" x 1.84")
(a) Excludes buttons, baseplate, and connectors.
