Max Filter Thickness When Using C-Mount Adapter: 0.050" (1.270 mm)
Mounting Features:
- Two 1/4"-20 Holes, One on Top & Bottom
- Four 4-40 Holes for 30 mm Cage Compatibility
- SM1 (1.035"-40) Threaded Aperture When C-Mount Adapter is Removed
Housing Dimmensions: 2.77" x 2.38" x 1.88" (70.4 mm x 60.3 mm x 47.6 mm)
Cooling: Passive Cooling
Cooling Mode Power Consumption: N/A
Power Supply: Powered by USB 3.0 from Host PC
Common Specifications
Sensor Type: Monochrome sCMOS
Effective Number of Pixels (Horizontal x Vertical): 1920 x 1080
Imaging Area (Horizontal x Vertical): 9.6768 mm x 5.4432 mm
Pixel Size: 5.04 µm x 5.04 µm
Optical Format: 2/3" (11 mm Diagonal)
Max Frame Rate: 50 fps (Full Sensor)
Sensor Shutter Type: Rolling
Peak Quantum Efficiency: 61% at 600 nm
Removable Window AR-Coating Reflectance: Ravg < 0.5% over 400 - 700 nm (Per Surface)
Exposure Time: 0.029 ms to 7767.2 ms in ~0.03 ms Increments
ADC(a) Resolution: 16 Bit
Vertical and Horizontal Digital Binning: Continuous Integer Values from 1 to 16
Region of Interest (ROI): 8 x 2 Pixelsb to 1920 x 1080 Pixels, Rectangular
Read Noise: <1 e- Median RMSc / <1.5 e- RMS
Digital Output: 16 Bit
Dynamic Range: Up to 87 dB
Full Well: ≥23 000 e-
Lens Mount: C-Mount (1.000"-32)
USB Power Consumption (Camera Only): 3.7 W @ 30 fps (Full Sensor ROI). 4.3 W @ 50 fps (Full Sensor ROI)
Operating Temperature: 10°C to 40°C (Non-Condensing)
Storage Temperature: 0°C to 55°C
(a) ADC = Analog-to-Digital Converter
(b) When Binning at 1 x 1
(c) As Specified by the Sensor Manufacturer
