Sensor Type: NIR-Enhanced CMOS
Effective Number of Pixels: 1280 x 1024 (H x V)
Imaging Area: 6.144 mm x 4.915 mm (H x V)
Pixel Size: 4.8 µm x 4.8 µm
Optical Format(a): 1/2" (7.76 mm Diagonal)
Max Frame Rate: 165.5 fps (Full Sensor)
ADC(b) Resolution: 10 Bits
Sensor Shutter Type: Global
Read Noise: <7.0 e- RMS
Full Well Capacity: ≥10 000 e-
Exposure Time: 0.100 ms to 59269 ms in 0.001 ms Increments
Vertical and Horizontal Digital Binning(c): 1 x 1 to 5 x 5
Region of Interest (ROI): 16 x 2 Pixels(d )to 1280 x 1024 Pixels, Rectangular
Dynamic Range: >60 dB
Peak Quantum Efficiency: 60% at 600 nm
Removable Optic: Window, Ravg < 0.5% per Surface (650 - 1050 nm)
USB Power Consumption: 3.85 W @ 165.5 fps (Full Sensor ROI)
Ambient Operating Temperature: 10 °C to 40 °C (Non-Condensing)
Storage Temperature: 0 °C to 55 °C
(a) Click the links for a visual comparison of all the sensor sizes.
(b) ADC = Analog-to-Digital Converter
(c) For color cameras, binning greater than 1 x 1 is only available when the camera is operating in unprocessed mode (monochrome).
(d) When Binning at 1 x 1
