Width: 3 mm
Height: 1.02 mm
Length: 3 mm
Shutdown: No Shutdown
Input Type: Differential
Unit Weight: 24.400 mg
3 dB Bandwidth: 100 MHz
Amplifier Type: High Speed, Low Noise
Mounting Style: SMD/SMT
SR - Slew Rate: 100 V/us
Development Kit: THS4032EVM
Moisture Sensitive: Yes
Number of Channels: 2 Channel
Supply Voltage - Max: 32 V
Supply Voltage - Min: 9 V
Ib - Input Bias Current: 20 uA
Operating Supply Current: 10 mA
Operating Supply Voltage: 33 V
Ios - Input Offset Current: 250 nA
Output Current per Channel: 90 mA
Vos - Input Offset Voltage: 2 mV
GBP - Gain Bandwidth Product: 120 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 1.6 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 80 dB
PSRR - Power Supply Rejection Ratio: 85 dB
