Width: 6.35 mm
Height: 4.57 mm
Length: 19.3 mm
Shutdown: No Shutdown
Input Type: FET
Technology: JFET
Supply Type: Dual
Unit Weight: 1 g
Amplifier Type: Low Noise Amplifier
Mounting Style: Through Hole
SR - Slew Rate: 10 V/us
Voltage Gain dB: 110 dB
Number of Channels: 4 Channel
Dual Supply Voltage: +/- 15 V
Supply Voltage - Max: 36 V
Supply Voltage - Min: 9 V
Ib - Input Bias Current: 50 pA
Operating Supply Current: 1.5 mA
Operating Supply Voltage: +/- 4.5 V to +/- 18 V
Vcm - Common Mode Voltage: Negative Rail + 3 V to Positive Rail - 1 V
Output Current per Channel: 25 mA
Vos - Input Offset Voltage: 1.5 mV
Maximum Dual Supply Voltage: +/- 18 V
Minimum Dual Supply Voltage: +/- 4.5 V
GBP - Gain Bandwidth Product: 4 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.003 pA/sqrt Hz
en - Input Voltage Noise Density: 15 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 80 dB
