Texas Instruments ISO7721QDWVRQ1 ອິໂຊເລເຕີດິຈິຕອນທີ່ເພີ່ມຄວາມແຂງແຮງຄວາມໄວສູງ ສໍາລັບລົດຍົນ E MC ທົດສອບສອງຊ່ອງ 1/

Polarity: Unidirectional

Shutdown: No Shutdown

Data Rate: 100 Mb/s

Isolation Type: Capacitive Coupling

Mounting Style: SMD/SMT

Forward Channels: 1 Channel

Reverse Channels: 1 Channel

Isolation Voltage: 5000 Vrms

Maximum Fall Time: 3.9 ns

Maximum Rise Time: 3.9 ns

Moisture Sensitive: Yes

Number of Channels: 2 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 2.25 V

Pd - Power Dissipation: 110 mW

Propagation Delay Time: 17 ns

Pulse Width Distortion: 0.5 ns

Operating Supply Current: 1 mA, 1.7 mA, 2.2 mA, 7.3 mA

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
