Width: 5 mm
Height: 1.5 mm
Length: 6 mm
Fall Time: 4 ns, 4.6 ns
Rise Time: 16 ns, 10 ns
Technology: Si
Unit Weight: 316.400 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 N-Channel
Qg - Gate Charge: 16 nC, 20 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 12 W
Vgs - Gate-Source Voltage: - 8 V, + 10 V
Typical Turn-On Delay Time: 10 ns, 8.5 ns
Typical Turn-Off Delay Time: 20 ns, 23 ns
Id - Continuous Drain Current: 40 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 135 S, 160 S
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1.1 V, 750 mV
