Width: 3 mm
Height: 0.9 mm
Length: 3.15 mm
Fall Time: 1 ns
Rise Time: 5 ns
Technology: Si
Unit Weight: 27.300 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Development Kit: TPS25741EVM-802, TPS25741AEVM-802
Transistor Type: 1 N-Channel
Qg - Gate Charge: 15 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 29 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 2 ns
Typical Turn-Off Delay Time: 11 ns
Id - Continuous Drain Current: 39 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 37 S
Rds On - Drain-Source Resistance: 10.2 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1.1 V
