Width: 5 mm
Height: 1 mm
Length: 6 mm
Fall Time: 7 ns
Rise Time: 20 ns
Technology: Si
Unit Weight: 91.700 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 64 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 195 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 6 ns
Typical Turn-Off Delay Time: 40 ns
Id - Continuous Drain Current: 100 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 181 S
Rds On - Drain-Source Resistance: 1.19 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1.1 V
