Width: 4.9 mm
Height: 1 mm
Length: 6 mm
Fall Time: 9.2 ns
Rise Time: 18.3 ns
Technology: Si
Unit Weight: 100 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 13.3 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 3.1 W
Vgs - Gate-Source Voltage: - 16 V, + 16 V
Typical Turn-On Delay Time: 11.8 ns
Typical Turn-Off Delay Time: 15.2 ns
Id - Continuous Drain Current: 100 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 91 S
Rds On - Drain-Source Resistance: 2.9 mOhms
Vds - Drain-Source Breakdown Voltage: 25 V
Vgs th - Gate-Source Threshold Voltage: 1.6 V
