Width: 2 mm
Height: 0.75 mm
Length: 2 mm
Fall Time: 13.6 ns
Rise Time: 28 ns
Technology: Si
Unit Weight: 6 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 5.1 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.7 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 4.5 ns
Typical Turn-Off Delay Time: 11 ns
Id - Continuous Drain Current: 14.4 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 44 S
Rds On - Drain-Source Resistance: 9.3 mOhms
Vds - Drain-Source Breakdown Voltage: 12 V
Vgs th - Gate-Source Threshold Voltage: 580 mV
