Width: 7.52 mm
Height: 2.35 mm
Length: 18 mm
Input Type: Single-Ended
Resolution: 16 bit
Unit Weight: 730.800 mg
Architecture: SAR
Sampling Rate: 40 kS/s
Interface Type: Parallel, SPI
Mounting Style: SMD/SMT
Reference Type: External, Internal
Power Consumption: 28 mW
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Number of Converters: 1 Converter
Supply Voltage - Max: 5 V
Supply Voltage - Min: 5 V
Analog Supply Voltage: 4.75 V to 5.25 V
Digital Supply Voltage: 4.75 V to 5.25 V
Pd - Power Dissipation: 35 mW
Operating Supply Voltage: 5 V
INL - Integral Nonlinearity: +/- 1.5 LSB
SNR - Signal to Noise Ratio: 88 dB
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: - 1 /1.5 LSB
SINAD - Signal to Noise and Distortion Ratio: 88 dB
